Page 4–180
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
Type Hex Addr Dec Addr
P8.15 reserved
~ 080F 42064
P8.16 reserved
~ 0810 42065
P8.17 reserved
~ 0811 42066
P8.18 reserved
~ 0812 42067
P8.19 reserved
~ 0813 42068
Type Hex Addr Dec Addr
P8.20 PLC Buffer 1
R/W 0814 42069
P8.21 PLC Buffer 2
R/W 0815 42070
P8.23 PLC Buffer 4
R/W 0817 42072
P8.24 PLC Buffer 5
R/W 0818 42073
P8.25 PLC Buffer 6
R/W 0819 42074
P8.26 PLC Buffer 7
R/W 081A 42075
P8.27 PLC Buffer 8
R/W 081B 42076
P8.28 PLC Buffer 9
R/W 081C 42077
P8.29 PLC Buffer 10
R/W 081D 42078
P8.30 PLC Buffer 11
R/W 081E 42079
P8.31 PLC Buffer 12
R/W 081F 42080
P8.32 PLC Buffer 13
R/W 0820 42081
P8.33 PLC Buffer 14
R/W 0821 42082
P8.34 PLC Buffer 15
R/W 0822 42083
P8.35 PLC Buffer 16
R/W 0823 42084
P8.36 PLC Buffer 17
R/W 0824 42085
P8.37 PLC Buffer 18
R/W 0825 42086
P8.38 PLC Buffer 19
R/W 0826 42087
P8.39 PLC Buffer 20
R/W 0827 42088
Range/Units (Format: 16-bit unsigned) Default
0~65535
0
Parameters P8.20~P8.29 can be used for conveniently transferring data to third party devices.
These buffers are used as a data memory storage location so that other devices can access
them from those parameter addresses. Users can change these parameter value by keypad or
communication. This data will be retained on a power cycle.
The internal GS4 PLC can read and write to these Parameters (as well as all GS4 Parameters) using
the RPR (Read Parameter) and WPR (Write Parameter) functions. So, these buffers can be used
to transfer information from the internal PLC to external devices without having to program the
external device to read data separately from the internal PLC and the Drive.
