Automation Direct DURApulse GS4 User Manual

Page 4–200
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
tiMing chart P10.00 = 4: tiMe circulation + quantity cycle
Incorporates the logic of Mode 2 (Quantity Cycle) and Mode 1 (Time Circulation): Up to 4
similar-size pumps with equal run time.
Related parameters: P10.00, P10.01, P10.02, P10.03, P10.04, P10.05, P10.06, P10.07, P10.08
increasing deMand
MOTOR 1 ON GS4
MOTOR 1 ON
AC LINE POWER
MOTOR 2 ON
AC LINE POWER
MOTOR 3 ON
AC LINE POWER
MOTOR 2 ON GS4
MOTOR 3 ON GS4
MOTOR 4 ON GS4
1s*
1s*
1s*
P10-05 P10-05 P10-05
P10-03 P10-03 P10-03 P10-03 P10-03 P10-03
FREQ.
P10-06
RELA
Y
R1O
R2O.
RO10
RO11
RO12
RO13
RO14
*One second delay before start
of acceleration is not adjustable
,
and cannot be turned off.
decreasing deMand
P10-05 P10-04 P10-05 P10-04 P10-05 P10-04
MOTOR 1 ON AC LINE POWER
MOTOR 2 ON AC LINE POWER
MOTOR 3 ON AC LINE POWER
MOTOR 4 ON GS4 POWER
P10-08
FREQ.
RELAY
R1O
R2O
RO10
RO11
