Automation Direct DURApulse GS4 User Manual

Chapter 4: AC Drive Parameters
Page 4–201
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
(tiMing chart P10.00 = 4: tiMe circulation + quantity cycle (continued))
tiMe circulation + quantity cycle
MOTOR 2 ON GS4
MOTOR 1 ON
AC LINE POWER
MOTOR 2 ON
AC LINE POWER
MOTOR 3 ON GS4
1s*
P10-02 P10-05
P10-03 P10-03
FREQ.
P10-06
GS4 OUTPUT
RELAY
R1O
R2O
RO10
RO11
RO12
*One second delay before start
of acceleration is not adjustable,
and cannot be turned off.
tiMing chart P10.00 = 5: tiMe circulation + quantity control
Incorporates the logic of Mode 3 (Quantity Control) with Mode 1 (Time Circulation): one
drive-powered motor plus up to 8 auxiliary motors that have equal run time.
increasing deMand
P10-03 P10-05 P10-03
P10-05 P10-03 P10-05 P10-03
MOTOR 2 ON AC LINE POWER
MOTOR 3 ON AC LINE POWER
MOTOR 4 ON AC LINE POWER
P10-06
FREQ.
RELAY
R1O
R2O
RO10
RO11
P10.05
Motor 0 on GS4 AC Drive Power
