Page 4–4
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
v/hz ParaMeters suMMary (P2.xx)
For detailed information about the P2.xx parameter group, please refer to page 4–49.
GS4 Parameters Summary – V/Hz Parameters (P2.xx)
Parameter Range
Run
1)
Read/
Write
Modbus
Address
Settings
Hex Dec Default
2)
User
1) ♦ in the Run-Read/Write column indicates that the parameter can be set during RUN mode.
R/W indicates “read/write.”
Read indicates “read-only.”
2) Parameters can be restored to their default values using P9.08.
P2.00
Volts/Hertz Settings
0: General Purpose
1: High Starting Torque
(TQR)
2: Fans and Pumps
3: Custom
4: 1�5 Power Curve
5: Square Curve
R/W 0200 40513 0
P2.01
Slip Compensation Gain 0�00~10�00 ♦R/W 0201 40514
0� 00
(V/Hz mode)
1� 00
(Vector mode)
P2.02
Torque Compensation Gain 0~10 ♦R/W 0202 40515 0
P2.03
Torque Compensation Filter 0�001~10�000 sec ♦R/W 0203 40516 0�5
P2.04
Motor 1 Middle Output Frequency 1 0�00~600�00 Hz R/W 0204 40517 3�00
P2.05
Motor 1 Middle Output Voltage 1
230V: 0�0~240�0V
460V: 0�0~480�0V
♦R/W 0205 40518
G S4-
21P0~27P5: 15�0V
2010+: 14�0V
G S4-
41P0~47P5: 30�0V
4010+: 28�0V
P2.06
Motor 1 Middle Output Frequency 2 0�00~600�00 Hz R/W 0206 40519 3�00
P2.07
Motor 1 Middle Output Voltage 2
230V: 0�0~240�0V
460V: 0�0~480�0V
♦R/W 0207 40520
G S4-
21P0~27P5: 15�0V
2010+: 14�0V
G S4-
41P0~47P5: 30�0V
4010+: 28�0V
P2.08
Motor 1 Minimum Output Frequency 0�00~599�99 Hz R/W 0208 40521 1�50
P2.09
Motor 1 Minimum Output Voltage
23 0V: 0�0~240�0V
46 0V: 0�0~480�0V
♦R/W 0209 40522
G S4-
21P0~27P5: 9�0V
2010+: 7�0V
G S4-
41P0~47P5: 18�0V
4010+: 14�0V
P2.10
PWM Carrier Frequency
Note: there are iNterdepeNdeNcies
betweeN p2.10, p6.00/p6.02, p6.33,
p6.34. refer to parameter details
wheN settiNg these parameters.
2~15 kHz R/W 020A 40523
model specific; refer
to param� details
P2.11
Control Mode
0: V/Hz Open Loop Control
1: SVC Sensorless
♦R/W 020B 40524 0
P2.12
Motor 2 Middle Output Frequency 1 0�00~600�00 Hz R/W 020C 40525 3�00
P2.13
Motor 2 Middle Output Voltage 1
230V: 0�0~240�0V
460V: 0�0~480�0V
♦R/W 020D 40526
G S4-
21P0~27P5: 15�0V
2010+: 14�0V
G S4-
41P0~47P5: 30�0V
4010+: 28�0V
P2.14
Motor 2 Middle Output Frequency 2 0�00~600�00 Hz R/W 020E 40527 3�00
(table continued next page)
