96 BD FACSAria User’s Guide
Sort Layout
The Sort Layout window contains all sorting instructions and controls. The sort
layout designates which device will be used to collect sorted particles and which
particles will be sorted into each sort location. Up to four sort counters can be
displayed in the window to give ongoing status during a sort.
Only one sort layout can be open at a time, but you can create several layouts for
a single tube, as long as each sort layout has a different name. Sort layouts can
also be added to global worksheets. Sort layouts are available for up to nine
default collection devices. Additional custom devices can be defined. See Creating
a Custom Device on page 174.
Laser Delay (red) -36.00 -54.00 -40.00 -82.00
Laser Delay (violet) 36.00 54.00 40.00 82.00
Area Scaling (blue) 1.40 1.20 1.40 0.75
Area Scaling (red) 1.00 0.75 1.00 0.50
Area Scaling (violet) 0.80 0.35 0.50 0.25
Window Extension 2.00 2.00 2.00 4.00
a. Contact your BD Sales representative for information on the availability of the 85 and 130 micron
nozzles.
Table 3-1 Default Sort Setup values (continued)
BD FACSDiva v6.1 Setting 70 micron 85 micron
a
100 micron 130 micron
a
BD FACSDiva v6.0 Setting High Medium Low Custom
default collection
devices
