Honeywell Bendix/King AV8OR Handheld User’s Guide
Getting Started D200803000008
Page 1-4 Rev 5 Mar 2012
© Honeywell International Inc. Do not copy without express permission of Honeywell
FIG
NO
DISPLAY OR
CONTROL
DESCRIPTION
8 Microphone The microphone is used for
Bluetooth connections to cell
phones.
9 USB/Serial port This is used for a standard
USB connection to a PC to
download movies, pictures, E-
books and new updates to the
navigational software. Also
used for a RS 232 connection
to external hardware with an
optional cable.
10 AV-IN port Future expansion
11 Headset jac
The headset jack accepts a
standard headphone miniature
stereo adapter so the user can
listen to music or movies from
the unit.
12 Volume control knob The volume control controls
the volume of the sound
through the rear speaker or
the Headset jack if a headset
is plugged in.
13 External GPS antenna
jack
The remote GPS antenna jack
allows the user to plug in the
remote GPS antenna that is
supplied with the unit for
better satellite reception.
14 Stylus The stylus allows the user to
precisely tap the touch screen.
