Honeywell Bendix/King AV8OR Handheld User’s Guide
D200803000008 VFR Moving Map Function
Rev 5 Mar 2012 Page 2-15
© Honeywell International Inc. Do not copy without express permission of Honeywell
Topo
On Map
Topo
Off Map
Nexrad
Map
Metar,
Pirep,
Winds
Aloft
Maps
Airmet
Sigmet
Maps
Plan
Traffic X X X X X
Flight
Log Trail
X X X X X
Metar X X X
TFR X X X
Lightning X X X
Precip
Type
X
Nexrad X
Cloud
Top
X
Storm
Cell
X
Overlays are configured in the Map Setup section. The Topo On
Map Overlay page is shown in the figure below.
Figure 2-20:Topo On Map - Overlay Setup
Refer to the Map Setup section on page 2-148 for more information
on how to configure the im
age overlays.
