Honeywell Bendix/King AV8OR Handheld User’s Guide
D200803000008 Getting Started
Rev 5 Mar 2012 Page 1-3
© Honeywell International Inc. Do not copy without express permission of Honeywell
DISPLAYS AND CONTROLS
The table below describes the AV8OR displays and controls that are
displayed in Figure 1-3:
Table 1-1 Di
splays and Controls
FIG
NO
DISPLAY OR
CONTROL
DESCRIPTION
1 Touch screen 4.3 inch TFT touch screen.
The resolution is 480 x 272
pixels.
2 POWER key The POWER key is used to
turn the unit on and off and
also can put the unit into
Sleep mode and wake the unit
from Sleep mode.
3 MENU key The MENU key returns the
user to the main menu from
any program in the unit.
4 LED charging status
indicator
Shows the status of the
charging system while the unit
is being charged.
5 SD slot and SD card The SD slot holds a SD card
which contains the aviation
and automotive navigation
software.
6 LOCK tab The LOCK tab disables all
controls and stops the touch
screen from responding to
taps.
7 6 VDC power
connector
This connector lets the unit
receive power from an AC or
an automotive DC.
