Honeywell Bendix/King AV8OR Handheld User’s Guide
Appendix D200803000008
Page 6-10 Rev 5 Mar 2012
© Honeywell International Inc. Do not copy without express permission of Honeywell
An RS 232 to RS 422 Converter can be purchased from Telebyte,
Model 253 (telebyteusa.com).
The pinouts for the Bendix/King KDR 610 and the AV8OR are as
follows:
Table 6-4 KDR 610 Pinouts
KDR 610 Signal
Name
KDR 610 Pin
Out
AV8OR
Signal Name
AV8OR Pin
Out
422TXH P6101-15 RS 232 RX DB9-2
422TXL P6101-33
GROUND P6101-37 GROUND DB9-5
