Honeywell Bendix/King AV8OR Handheld User’s Guide
Basic Operation D200803000008
Page 2-2 Rev 5 Mar 2012
© Honeywell International Inc. Do not copy without express permission of Honeywell
A green check mark is placed to the right of each test item as it is
checked.
If the initial self-test fails, the unit is unable to continue operating
safely. A red is displayed in place of the check mark and the first
soft key changes to HELP, as shown in the figure below.
Figure 2-2: Self Test Failed
When the HELP soft key is tapped, a caution message is displayed
as shown in the figure below.
Figure 2-3: Self Test Failed Caution
The unit should be turned off and then turned back on. If
AV8OR still fails the self-test, please contact customer support.
If the self-test finishes successfully, the self-test window header
changes to SELF TEST COMPLETED in green, as shown in the
figure below.
