BENDIXKing XVUE TOUCH - Weight and Balance Analysis; Table 4-2 Wiring Harness Equipment; Table 4-3 Xvue Touch System Component Weights & Centers of Gravity

89000109-002 xVue Touch Installation Manual
Rev 2 Page 4-21
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
For new installations utilize the connectors, circuit card assembly, etc. included in the xVue Touch System
Installation Kits or in Installation Materials Required but Not Supplied and referenced in Table 4-2:
Wire routing, bend radius, and harness preparation should be in accordance with AC 43.13-1B Chapter 11
Sections 8 through 11. It is the installers’ responsibility to ensure the airworthiness of any additional
equipment interfaced to the xVue Touch System.
4.11 Weight and Balance Analysis
A revised weight and balance computation is required after the installation of the xVue Touch System.
The weight and balance report must be carried out in accordance with the guidance in AC 43.13-1B,
Chapter 10, Section 2, Paragraphs 10-16 through 10-23, pages 10-12 through 10-23.
Prepare a weight and balance report for the airplane records and verify that the airplane does not exceed
the authorized weight and Center of Gravity (CG) limits as shown in the Type Certificate Data Sheet
(TCDS) and airplane specification(s).
The various xVue Touch System components and associated nominal weights are listed in Table 4-3
below. Note: The connector and backshell weights are not included.
Table 4-2 Wiring Harness Equipment
Description Installation Kit PN Additional Information
KSD 100EXP Backshell Assembly Installation Kit 89000120-002 Table 3-3
KSD 100EXP Configuration Module and Connector
Installation Kit
89000120-003 Table 3-4
KCP 100EXP Control Panel Installation Kit 89000126-004 Table 3-6
KG 71EXP ADAHRS Installation Kit 89000123-007 Table 3-8
KMG 7010 Magnetometer Installation Kit 050-03643-0000 Table 3-9
MD32 Connector Kit 9019092-1 Table 3-9
KDC 100EXP Installation Kit 89000138-002 Table 3-11
Overbraid N/A Table 3-13
Table 4-3 xVue Touch System Component Weights & Centers of Gravity
xVue Touch System Components Part Number Weight (lb) Weight (kg) C of G
KSD 100EXP Primary Flight Display 89000120-001-[ ] 6.9 3.13 See Figure A-1
KSD 100EXP Installation Kit
(Mounting Hardware and Grip)
89000120-007 0.75 0.34 N/A
KG 71EXP ADAHRS 89000123-001-[ ] 2.0 0.91 SeeFigure A-6
KCP 100EXP Control Panel (Portrait)
KCP 100EXP Control Panel
(Landscape)
89000126-001-[ ]
89000126-003-[ ]
0.93 0.42 See Figure A-3
KCP 100EXP Installation Kit (Center
Stack - Landscape)
89000026-005 0.1 0.05 N/A
