89000109-002 xVue Touch Installation Manual
Rev 2 Page 2-6
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Table 2-4 KG 71EXP ADAHRS Specifications
Characteristic Specification
Dimensions 8.65 x 5.1 x 1.4 inches (219.72 x 129.43 x 35.56 mm)
Weight 2.2 lbs. (1.0 kgs.) Max. Weight
Current Draw Typical (28VDC): 0.2 AMP
Typical (14VDC): 0.4 AMP
Operating Voltage 9.0 to 32.2 VDC
(9VDC on battery backup, 11VDC for power-up, and 32.2VDC max)
Circuit Breaker 2 AMP for 28 VDC, 3 AMP for 14 VDC systems
Cooling Convection cooled (does not required forced air cooling within the unit
operational temperature range, refer to Section 3.6.7.3 for cooling
considerations)
Connectors Male 50-pin D-sub
Female 9-pin D-sub (Maintenance port)
Table 2-5 KG 71EXP ADAHRS Performance Characteristics
Characteristic Specification
Time to Initialize Up to 3 min
Airspeed Range 20 to 350 kts
Altitude Range -1,000 to 35,000 ft
Vertical Speed Range -20,000 to 20,000 ft/min
Baro-Correction Range 22 to 31.50 InHg
Roll/Pitch Accuracy DO 334 Category A4
Roll/Pitch Range Roll: ± 180 Degrees
Pitch: ± 90 Degrees
Heading Accuracy DO 334 Category H4
Heading Range ±180 Degrees
Slip/Skid Accuracy DO 334 Category T3
Slip/Skid Range DO 334 Category T3, Max. range ±8.5 Degrees
Turn Rate Output Accuracy DO 334 Category T3
Turn Rate Output Range ±128 Degrees/Second
Max Pitch/Roll/Yaw Rate ± 245 deg/sec
Max Sustained G ± 4g
