Rev C, March 30, 2018 6 Manual Number 9019050
1.2 TECHNICAL SPECIFICATIONS
Electrical Attributes
Input Voltage: 7 – 32 VDC
Input Power: 0.56 watts
Output Data: ARINC 429 (proprietary format)
Table 1.1
Physical Attributes
Weight: 3.0 ounces (.085 kg)
Dimensions:
(not including connector mate)
3.0 inches x 2.75 inches x 0.81 inches (LxWxH)
Mating Connector: MCI P/N 8017287
Mounting: Base mount – any orientation
Table 1.2
Performance Limits
Heading Accuracy vs. Latitude:
Within +/-2° up to 55°N or 45°S;
increasing error towards the magnetic N and S poles
Altitude: +55,000 feet
Temperature: -55°C to +70°C (-67°F to +158°F)
Table 1.3
Qualifications
Certification: FAA TSO-C6e
Environmental Qualification:
RTCA/DO-160G Environmental Category;
See Section 3.2
Software Qualification: RTCA/DO-178C, Design Assurance Level A
Table 1.4
