89000109-002 xVue Touch Installation Manual
Rev 2 Page 2-18
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Table 2-15 KDC 100EXP Environmental Qualification Form (EQF)
DO-160G
Section
Conditions Category Notes
4.0 Temperature B2 Operating Low Temperature = -45°C
Operating High Temperature = +70°C
8.0 Vibration S Curve M
Table 2-16 KTP 73 Environmental Qualification Form (EQF)
DO-160G
Section
Conditions Category Notes
4.0 Temperature and Altitude D2 -55°C/70°C, -55°C/70°C Short Term
-55°C/85°C Storage, 50,000 ft
In-flight Loss of Cooling (Not Applicable)
5.0 Temperature Variation A 10°C per minute
6.0 Humidity C
7.0 Operational Shocks and Crash Safety A 6 g, 11 ms Pulse
Crash Safety (Impulse & Sustained) – no test
performed
8.0 Vibration S(Curve M & T) Zone 2 & Zone 5
9.0 Explosive Atmosphere X
10.0 Waterproofness S
11.0 Fluids Susceptibility F (Solvents & Cleaning Fluids, De-Icing Fluid)
12.0 Sand and Dust X
13.0 Fungus Resistance X
14.0 Salt Fog S
15.0 Magnetic Effect Z
16.0 Power Input X
17.0 Voltage Spike X
18.0 Audio-Frequency Conducted
Susceptibility
X
19.0 Induced Signal Susceptibility X
20.0 Radio Frequency Susceptibility
(Radiated and Conducted)
X
21.0 Emission of Radio Frequency Energy X
22.0 Lightning Induced Transient Susceptibility X
23.0 Lightning Direct Effects XX2A
24.0 Icing X
25.0 Electrostatic Discharge X
26.0 Flammability C Analysis Only
To Next Page
