89000109-002 xVue Touch Installation Manual
Rev 2 Page 3-11
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
3.4 Unpacking and Inspection
Exercise caution when unpacking the xVue Touch System equipment. Confirm receipt of all installation
components refer to, Table 3-2, for the appropriate part lists. Inspect all components for any damage,
contact BendixKing Customer Support if any parts are missing or damaged. The shipping container and all
packing materials must be retained in the event that storage or reshipment of the equipment is
necessary. If a damage claim is needed, the shipping container and all packing materials will be used to
substantiate your claim. The claim must be filed as soon as possible.
9502-10-0-0 K694 Crimper Turret Head, Positioner Positronic
D-sub 50 Socket and Pin Connector Tools for the KG 71EXP ADAHRS Installation Kit
(89000123-007)
M81969/1-04 RED and White Metal Insert/Removal Tools
AMF8 Crimp Tool M22520/2-01
K13-1 Crimper Turret Head, Positioner M22520/2-08
D-sub 9 Socket Connector Tools for the KMG 7010 Magnetometer Installation Kit
(050-03643-0000)
M81969/1-02 Red and White Metal Insert/Removal Tools
AFM8 Crimp Tool M22520/2-01
9502-10-0-0 K694 Crimper Turret Head, Positioner Positronic
D-sub 9 Socket Connector Tools for the MD32 Magnetometer Connector Kit
(9019092-1)
M81969/1-02 Red and White Metal Insert/Removal Tools
AFM8 Crimp Tool M22520/2-01
9502-10-0-0 K694 Crimper Turret Head, Positioner Positronic
D-sub 9 Socket Connector Tools for the KDC 100EXP Installation Kit
(89000138-002)
M81969/1-02 Red and White Metal Insert/Removal Tools
AFM8 Crimp Tool M22520/2-01
9502-10-0-0 K694 Crimper Turret Head, Positioner Positronic
Table 3-14 Tools Required But Not Supplied
Part Number or Specification Description Notes
NOTE
THE KSD 100EXP, KCP 100EXP, KG 71EXP AND KMG 7010/MD32 EXTERNAL CONNECTORS
SHOULD BE PROTECTED WITH AN ESD COVER WHEN NOT INSTALLED ON THE AIRPLANE.
