89000109-002 xVue Touch Installation Manual
Rev 2 Page 2-5
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
2.3.6 KTP 73 OAT Probe
The KTP 73 OAT probe measures air temperature and provides the data to the KG 71EXP. Total air
temperature is sensed by the independent probe. The temperature probe is a platinum 500 Ohm thermal
sensor. Total air temperature is used to calculate the OAT and is required for the true airspeed
calculation.
2.4 Technical Specifications
Table 2-2 KSD 100EXP Primary Flight Display Specifications
Characteristic Specification
Dimensions 6.897 x 10.45 x 4.08 inches (175.18 x 265.43 x 103.63 mm)
Mounting Information Front mount
Weight 7.59 lbs. (3.44 kgs.) Max. Weight
Current Draw Typical (28VDC): 1.33 AMP
Typical (14VDC): 2.66 AMP
Operating Voltage 9.0 to 32.2 VDC
(9VDC on battery backup, 11VDC for power-up, and 32.2VDC max)
Circuit Breaker 2 AMP for 28 VDC, 3 AMP for 14 VDC systems
Cooling Convection cooled (does not required forced air cooling within the unit
operational temperature range, refer to Section 3.6.5.2 for cooling
considerations)
Connectors 2 D-sub connectors (Female 78-pin and Male 78-pin)
Viewing Angle Envelope 80 degree max viewing angle from all directions
Table 2-3 KCP 100EXP Control Panel Specifications
Characteristic Specification
Dimensions 1.48 x 6.25 x 3.67 inches (37.6 x 158.8 x 93.2 mm)
Mounting Information Front mount
Weight 1.02 lbs. (0.46 kgs.) Max. Weight
Current Draw The KCP 100EXP is powered from KSD 100EXP and the KCP 100EXP
current draw is included with the KSD 100EXP values shown in Table 2-2.
Operating Voltage Operating Voltage is provided by the KSD 100EXP.
Circuit Breaker The KCP 100EXP is powered from KSD 100EXP. The circuit breaker
defined under the KSD 100EXP Primary Flight Display Specifications is
sufficient.
Cooling Convection cooled (does not required forced air cooling within the unit
operational temperature range)
Connectors Male 9-pin D-Sub
