BENDIXKing XVUE TOUCH - Table 6-7 KMG 7010;MD32 Installation Orientation Options

89000109-002 xVue Touch Installation Manual
Rev 2 Page 6-48
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Orientations in the CMT do not match the MD32 orientations. Use Table 6-7 to map the MD32
orientations to the corresponding CMT image and number.
Table 6-7 KMG 7010/MD32 Installation Orientation Options
KMG Mounting
Location
KMG Connector
Location
MD32 Mounting
Location
MD32 Connector
Location
KMG CMT
Image #
Up Back Down Right 7
Up Left Down Back 16
Up Front Down Left 3
Up Right Down Front 15
Down Back Up Left 5
Down Left Up Front 14
Down Front Up Right 1
Down Right Up Back 13
Back Down Front Right 10
Back Left Front Down 20
Back Up Front Left 12
Back Right Front Up 18
Front Up Back Right 9
Front Right Back Down 17
Front Down Back Left 11
Front Left Back Up 19
Left Back Right Up 6
Left Down Right Back 22
Left Front Right Down 2
Left Up Right Front 23
Right Back Left Down 8
Right Down Left Front 21
Right Front Left Up 4
Right Up Left Back 24
