BENDIXKing XVUE TOUCH - Table 3-4 Installation Kit, Configuration Module & Connectors - KSD 100 EXP, PN 89000120-003; Table 3-5 Installation Kit, Mounting Hardware and Grip - KSD 100 EXP, PN 89000120-007; Table 3-6 KCP 100 EXP Control Panel Installation Kit for Portrait Mounting, PN 89000126-004; Table 3-7 KCP 100 EXP Control Panel Installation Kit for Landscape Mounting, PN 89000126-005

89000109-002 xVue Touch Installation Manual
Rev 2 Page 3-6
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
MS51959-17 Phillips Flat Head Countersunk Screws 4 EA
7024206-10 Captive Socket Head Cap Screws 4 EA
MS51957-13 Phillips Pan Head Screws 22 EA
MS35335-57 Lock Washers 22 EA
Table 3-4 Installation Kit, Configuration Module & Connectors – KSD 100EXP, PN 89000120-003
Part Number Description Qty UM
89400020-064 Circuit Card Assembly, Programmed, Configuration
Module
1EA
53504890-1 78-pin D-Sub Male Connector 1 EA
53504891-2 Connector Contact Crimp Pin Size 22 78 EA
53501676-2 78-pin D-Sub Female Connector 1 EA
53504891-1 Connector Contact Crimp Socket Size 22 78 EA
Table 3-5 Installation Kit, Mounting Hardware and Grip - KSD 100EXP, PN 89000120-007
Part Number Description Qty UM
89500020-024 KSD 100EXP Grip 1 EA
MS51957-1B #2-56 X 1/8 inch Pan Head Screws 8 EA
NAS1352-08-10 #8-32 X 5/8 inch Socket Head Cap Screws 4 EA
Table 3-6 KCP 100EXP Control Panel Installation Kit for Portrait Mounting, PN 89000126-004
Part Number Description Qty UM
53504988-1 Connector, SD Series, 9 Pin 1 EA
53504891-3 Contacts – Size 20 9 EA
D9000GE0/AA Connector Backshell REF REF
Table 3-7 KCP 100EXP Control Panel Installation Kit for Landscape Mounting, PN 89000126-005
Part Number Description Qty UM
89500026-010 KCP 100 Center Stack Adapter 1 EA
MS51957-33 #6-32 X 7/8 inch Pan Head Screw 4 EA
089-02353-0001 #6-32 Self Locking Clip Nut 4 EA
Table 3-3 Installation Kit, Backshell Assembly – KSD 100EXP, PN 89000120-002
Part Number Description Qty UM
