89000109-002 xVue Touch Installation Manual
Rev 2 Page 8-23
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
8.6 Repair and Return
If repair is necessary, the units must be sent to a BendixKing repair facility. There are no field repairable
items inside the xVue Touch LRUs.
KSD OVERTEMP
KSD 100EXP Unit Temperature Is
Too High
• Turn KSD 100EXP off to allow it
to cool down
• Check for adequate ventilation
• Check airflow around the KSD
100EXP for any blockages
WARNING TERRAIN TERRAIN Warning during flight Comply with Warning
WARING OBSTACLE OBSTACLE Warning during flight Comply with Warning
CAUTION TERRAIN TERRAIN Caution during flight Comply with Caution
CAUTION OBSTACLE OBSTACLE Caution during flight • Comply with Caution
ATTITUDE ALIGNING Attitude is in alignment
• Let system align
• If system will not complete
alignment use Table 8-4 for
troubleshooting the KG 71EXP
system.
Table 8-6 Alerts Troubleshooting Chart
Symptom Causes Corrective Action
