89000109-002 xVue Touch Installation Manual
Rev 2 Page 6-45
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Table 6-5 KG 71EXP AHRS Output Labels
Label ID (Octal) Label Name Label Type Default Transmit Rate [Hz]
377 Equipment Identification DISC 80
270 AHRS Discrete#1 DISC 80
320 Magnetic Heading BNR 80
324 Pitch Angle BNR 80
325 Roll Angle BNR 80
326 Body Pitch Rate BNR 80
327 Body Roll Rate BNR 80
330 Body Yaw Rate BNR 80
331 Body Longitudinal Acceleration BNR 80
332 Body Lateral Acceleration BNR 80
333 Body Normal Acceleration BNR 80
336 Inertial Pitch Rate BNR 80
337 Inertial Roll Rate BNR 80
340 Inertial Yaw Rate BNR 80
364 Vertical Acceleration BNR 80
365 Inertial Vertical Velocity BNR 80
Table 6-6 KG 71EXP Air Data Output Labels
Label ID (Octal) Label Name Label Type Default Transmit Rate [Hz]
377 Equipment Identification DISC 20
162 Density Altitude BNR 20
203 Altitude BNR 20
204 Baro-Corrected Altitude BNR 20
206 Computed Airspeed BNR 20
210 True Airspeed BNR 20
211 Total Air Temperature BNR 20
212 Altitude Rate BNR 20
213 Static Air Temperature BNR 20
234 Baro Correction (mb) BNR 20
242 Total Pressure BNR 80
