Rev C, March 30, 2018 12 Manual Number 9019050
3.2 ENVIRONMENTAL QUALIFICATION STATEMENT
NOMENCLATURE:
Remote Magnetometer TSO APPROVAL: C6e
MODEL NUMBER: MD32 PART NUMBER: 6420032-( ) series
MANUFACTURER: Mid-Continent Instrument Co., Inc.
MANUFACTURERS SPECIFICATIONS: Test Specification (TS) 715, Test Data Sheet (TDS) 715
QUALIFICATION STANDARD: RTCA/DO-160G, dated 12/08/10
CONDITIONS SECTION DESCRIPTION OF TEST
Temperature and Altitude
Low Temperature
High Temperature
Altitude
4
4.5.2
4.5.4
4.6.1
Category F2
Operating Low Temp = -55C
Operating High Temp = +70C
Altitude = +55,000 ft.
Temperature Variation 5 Category S2
Humidity 6 Category B
Operational Shock and
Crash Safety
7 Category B
Vibration 8 Category R; Curves E, E1
[REE1]
Explosion 9 Category X
Waterproofness 10 Category W
Fluids 11 Category X
Sand and Dust 12 Category X
Fungus 13 Category X
Salt Fog 14 Category S
Magnetic Effect 15 Category Z
Power Input 16 Category Z
Voltage Spike 17 Category A
Audio Frequency Conducted
Susceptibility
18 Category Z
Induced Signal Susceptibility 19 Category ZC
Radio Frequency Susceptibility 20
Category W (conducted)
Category F (radiated)*
[WF]
Emission of Radio Freq Energy 21 Category M
Lightning Induced Transient
Susceptibility
22
Category B3 (pin injection)
Category K3L3 (cable bundle)
[B3K3L3]
Lightning Direct Effects 23 Category X
Icing 24 Category X
ESD 25 Category A
Flammability 26 Category X
REMARKS:
Sections 20: Radiated susceptibility complies with Category G from 100-400MHz and Category F from 400-
18,000MHz.
