89000109-002 xVue Touch Installation Manual
Rev 2 Page 3-13
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
3.5.1.1.2 Discrete Outputs
3.5.1.2 Serial I/O
RS-232: Electrical characteristics are per ANSI TIA/EIA-232-F.
RS-422: Electrical characteristics are per ANSI TIA/EIA-422-A.
3.5.1.3 ARINC 429 I/O
Electrical characteristics are per ARINC 429.
3.5.1.4 ARINC 453 I/O
This bus format is 1600 bit Manchester bi-phase per ARINC 708A. The data rate on this bus is 1 Mbit/s.
3.6 Installation Considerations
In general, equipment must be installed in a location convenient for operation, inspection, and
maintenance, and in an area free from excessive vibration, heat, and EMI noise generating sources.
The location consideration for each of the xVue Touch System components is described in this section.
Table 3-19 KSD 100EXP Discrete Output Ground/Open (DOGO) States
State Voltage Level
Active 0 VDC
Inactive Open Circuit
Table 3-20 KSD 100EXP Discrete Output 5V/Open (DO5VO) States
State Voltage Level
Active 5 VDC
Inactive Open Circuit
Table 3-21 KSD 100EXP Discrete Output 28V/Open (DO28VO) States
State Voltage Level
Active 28 VDC
Inactive Open Circuit
