89000109-002 xVue Touch Installation Manual
Rev 2 Page 3-12
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
3.5 System Interfaces
3.5.1 Standard Interface Definitions
Unless otherwise stated, the following interface definitions will apply.
3.5.1.1 Discrete I/O
3.5.1.1.1 Discrete Inputs
Refer to the tables below for the discrete input states.
Table 3-15 KSD 100EXP Discrete Input Ground/Open (DIGO) States
State Voltage Level
Active 0 VDC
Inactive Open Circuit
Table 3-16 KSD 100EXP Discrete Input 5V/Open (DI5VO) States
State Voltage Level
Active 5 VDC
Inactive Open Circuit
Table 3-17 KSD 100EXP Discrete Input 15V/Open (DI5VO) States
State Voltage Level
Active 15 VDC
Inactive Open Circuit
Table 3-18 KSD 100EXP Discrete Input 28V/Open (DI28VO) States
State Voltage Level
Active 28 VDC
Inactive Open Circuit
