89000109-002 xVue Touch Installation Manual
Rev 2 Page 3-7
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Table 3-8 KG 71EXP Installation Kit PN 89000123-007
Part Number Description Qty UM
53501396-4 50-pin D-Sub Female Connector 1 EA
M39029-63-368 Contacts 50 EA
53504975-1 Connector Backshell, D-Sub, w/Jackscrews 1 EA
Table 3-9 KMG 7010 Installation Kit PN 050-03643-0000
Part Number Description Qty UM
030-03519-0001 Connector, D-Sub, Receptacle, Hsg, Brass Shell, 9-
Pos
1EA
155-01771-0000 KMG 7010 Installation Drawing REF REF
001-01299-0000 Instruction For Harness Assembly Parts REF REF
010-00068-0002 Crimp Terminal 4S 1 EA
030-01157-0011 Socket Crimp 20G 9 EA
030-01499-0011 Connector, D-Sub, Hood, EMI/RFI, Metal,
Jackscrews, 9-Pos
1EA
057-05944-0044 TSO Label, KMG 7010 1 EA
089-02162-0055 Nut Lock 10-32 4 EA
089-06015-0010 Screw Flat Head Phillips 10-32 X 5/8 4 EA
089-06293-0003 Screw Flat Head Phillips 3-48 X 3/16 1 EA
089-06298-0005 Screw Flat Head Phillips 3-48 X 5/16 4 EA
089-06298-0008 Screw Flat Head Phillips 3-48 X 1/2 2 EA
089-08029-0040 Passivated SS Non-Magnetic Flat Std. #10 Washer 4 EA
Table 3-10 MD32 Connector Kit PN 9019092-1
Part Number Description Qty UM
9019092-1 Connector, D-Sub, Receptacle, Hsg, Brass Shell, 9-
Pos
1EA
Table 3-11 KDC 100EXP Installation Kit PN 89000138-002
Part Number Description Qty UM
53505633-1 Connector, D-Sub 1 EA
