89000109-002 xVue Touch Installation Manual
Rev 2 Page 2-9
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
2.5 Environmental Qualification Form (EQF)
The following table provides the DO-160G Environmental categories for the xVue Touch System
components.
Table 2-10 KSD 100EXP Environmental Qualification Form (EQF)
DO-160G
Section
Conditions Category Notes
4.0 Temperature and Altitude A1/C1 -20°C/+55°C, -40°C/+70°C Short Te rm ,
-55°C/+85°C Storage, 35,000 ft./-15,000ft
In-flight Loss of Cooling (Not Applicable)
5.0 Temperature Variation C 2°C/minute
6.0 Humidity A
7.0 Operational Shocks and Crash Safety B A/C Type 3, Test R
8.0 Vibration S (curve M) Zone 2
9.0 Explosive Atmosphere X
10.0 Waterproofness X
11.0 Fluids Susceptibility X
12.0 Sand and Dust X
13.0 Fungus Resistance X
14.0 Salt Fog X
15.0 Magnetic Effect Z
16.0 Power Input BXX
17.0 Voltage Spike A
18.0 Audio-Frequency Conducted
Susceptibility
B
(See Note 1)
19.0 Induced Signal Susceptibility ZCX
(See Note 2)
20.0 Radio Frequency Susceptibility
(Radiated and Conducted)
Q
(See Note 4 & 5)
21.0 Emission of Radio Frequency Energy M
22.0 Lightning Induced Transient Susceptibility A3J3L3
23.0 Lightning Direct Effects X
24.0 Icing X
25.0 Electrostatic Discharge A
26.0 Fire, Flammability C
(See Note 3)
