89000109-002 xVue Touch Installation Manual
Rev 2 Page 5-12
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
5.7 KTP 73
5.8 Configuration Module
Table 5-10 KTP 73 Wire Descriptions
Wire Color Description I/O
Red TEMP3 Out
Black TEMP1 Out
White TEMP2 Out
Table 5-11 Configuration Module (J2 Backshell) Pin Descriptions
Pin Description I/O
E1 APM_SO Out
E2 APM_SI In
E3 APM_SCLK In
E4 APM_CS_N In
E5 APM_WP_N In
E6 APM_PWR_3P3VDC PWR
E7 APM_PWR_RTN GND
