89000109-002 xVue Touch Installation Manual
Rev 2 Page 2-17
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Table 2-14 MD32 Environmental Qualification Form (EQF)
DO-160G
Section
Condition Category Notes
4.0 Temperature and Altitude F2 Operating Low Temp = -55C
Operating High Temp = +70C
Altitude = +55,000 ft.
5.0 Temperature Variation S2
6.0 Humidity B
7.0 Operational Shocks and Crash Safety B
8.0 Vibration R (curves E, E1)
[REE1]
9.0 Explosion X
10.0 Waterproofness W
11.0 Fluids X
12.0 Sand and Dust X
13.0 Fungus Resistance X
14.0 Salt Fog S
15.0 Magnetic Effect Z
16.0 Power Input Z
17.0 Voltage Spike A
18.0 Audio Frequency Conducted Susceptibility Z
19.0 Induced Signal Susceptibility ZC
20.0 Radio Frequency Susceptibility (Radiated
and Conducted)
WF
21.0 Emission or Radio Frequency Energy M
22.0 Lightning Induced Transient Susceptibility B3K3L3 B3 (pin injection)
K3L3 (cable bundle)
23.0 Lightning Direct Effects X
24.0 Icing X
25.0 Electrostatic Discharge (ESD) A
N/A Fire, Flammability X
Notes:
Sections 20: Radiated susceptibility complies with Category G from 100-400MHz and Category F from 400-18,000MHz.
