89000109-002 xVue Touch Installation Manual
Rev 2 Page 2-16
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Higher Levels DO-160E methodology/HPN: 004-02256-6232
DO-160G Vibration Qualification level: Cat R (Curves (E, E1)
High Power:
Frequency Range (Hz) 70-140
Sweep Rate (Hz/sec) 0.05
Peak Accel (g) = 2.5
Windmilling:
2. Section 19.3.1 was not run due to the magnetic fields generated during the test. Since the KMG 7010 measures mag-
netic fields and the fields generated during the test would be larger than the earth’s magnetic field, the unit cannot be
expected to pass and therefore, was not tested.
23.0 Lightning Direct Effects X Not Tested
24.0 Icing A
25.0 Electrostatic Discharge (ESD) A
N/A Fire, Flammability Not Applicable Supplemental Testing beyond DO-160D
DO-160G Section 26 Cat C Labels only / HPN:
004-02256-6232
Notes:
1. Supplemental Vibration Testing beyond DO-160D
Fan Blade Off (FBO) DO-160E methodology/HPN: 004-02256-6220
Zone 18
CMCF
UUT Frequency
30.5-28.5 28.5-25.5 25.5-22.5 22.5-18.5 18.5-9.5
Pk (g) Pk (g) Pk (g) Pk (g) Pk (g)
X X 1.51 2.58 2.46 2.39 1.36
Y Y 2.50 2.50 2.50 3.57 2.08
Z Z 5.30 9.39 10.92 6.29 2.89
Sweep Rate (Hz/sec) .0055 .0062 .0666 .0041 .0090
Table 2-13 KMG 7010 Environmental Qualification Form (EQF)
DO-160G
Section
Condition Category Notes
Frequency
Range
Sweep
Rate
Peak Accel (g)
X1 Y1 Z1
10.0-15.5 0.00833 1.0 3.0 2.8
15.5-19.5 0.00417 1.0 4.1 3.1
19.5-22.5 0.00167 1.0 3.4 1.9
22.5-26.5 0.00111 1.0 3.7 2.1
26.5-31.0 0.00833 1.0 2.2 1.2
