89000109-002 xVue Touch Installation Manual
Rev 2 Page 3-5
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
3.2 Available Equipment
The xVue Touch System may be configured based on the combinations of equipment and install kits
shown in Table 3-2.
3.3 Installation Materials
Table 3-2 xVue Touch System Components and Kits
Description PN
KSD 100EXP Primary Flight Display 89000120-001-[ ]
KCP 100EXP Control Panel (Portrait) 89000126-001-[ ]
KCP 100EXP Control Panel (Landscape) 89000126-003-[ ]
KG 71EXP ADAHRS 89000123-001-[ ]
KMG 7010 Magnetometer
OR
MD32 Magnetometer
065-00189-0101
(1)
6420032-[ ]
KDC 100EXP Data Converter
89000138-001 -[ ]
(2)
KTP 73 OAT Probe 89000025-001-[ ]
KSD 100EXP Backshell Assembly Install Kit 89000120-002
KSD 100EXP Configuration Module
& Connectors Install Kit 89000120-003
KSD 100EXP Mounting Hardware and Grip Install Kit 89000120-007
KCP 100EXP Control Panel Install Kit for Portrait Mounting 89000126-004
KCP 100EXP Control Panel Install Kit for Landscape
Mounting
89000126-005
(3)
KG 71EXP ADAHRS Install Kit 89000123-007
KMG 7010 Magnetometer Install Kit 050-03643-0000
REV E
MD32 Magnetometer Connector Kit 9019092-1
KDC 100EXP Data Converter Install Kit 89000138-002
Note
(1)
Either a KMG 7010 or MD32 and KDC 100EXP can be configured to provide the magnetometer
function for the xVue Touch System.
Note
(2)
Included with the MD32 Magnetometer.
Note
(3)
Only needed for radio stack DZUS rail mounting of the KCP 100EXP Control Panel (Landscape)
and to be used in conjunction with the KCP 100EXP Control Panel Installation Kit.
Table 3-3 Installation Kit, Backshell Assembly – KSD 100EXP, PN 89000120-002
Part Number Description Qty UM
89499999-002 Backshell Cover 2 EA
89499999-003 Backshell Base 2 EA
MS3367-7-9 Self-Cinching Tiedown Strap 2 EA
