89000109-002 xVue Touch Installation Manual
Rev 2 Page 3-8
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
3.3.1 Accessories and Support Equipment Available from BendixKing
3.3.2 Materials Required but Not Supplied
The xVue Touch System is intended for use with standard aviation accessories. The following items are
required for installation but not supplied:
53505184-1 Connector Accessory, D-Sub 1 EA
M39029/63-368 Contact, Socket 15 EA
MS24693-C273 Screw, Machine, Flat 4 EA
NAS1149-
C0332R
Washer, Flat 4 EA
MS21083-N3 Nut, Self Locking 4 EA
Table 3-12 xVue Touch System Accessories and Support Equipment
Unit PN Description Note
89600023-006.01.01 Configuration and
Maintenance Tool
Test/calibration PC software to be used
with Maintenance PC for configuring the
KG 71EXP and MD32, and performing the
post installation compass verification.
Table 3-13 Installation Materials Required but Not Supplied
Description PN or Specification Quantity Note
Wire 22, 20, 18, 16 AWG M22759/16-X-Y As Required ETFE jacket
X = Size Y=COLOR
Twisted Shielded Pair Wire 22 AWG M27500-22 As Required TE, TG or ETFE jacket
Twisted Shielded Triple Wire 22
AWG
M27500-22 As Required TE, TG or ETFE jacket
Wire 24 AWG M27500-24 As Required TE, TG or ETFE jacket
Twisted Shielded Single Wire 22
AWG
M27500-22 As Required TE, TG or ETFE jacket
77 OHM Jacket Coax Cable MIL-C-17/176-
00002
As Required For A708/ 453 connections
DB-9 (Female) Connector 205203-3 1 KG 71EXP Maintenance Port
#4, 6, 8, 10, ¼ inch Ring Terminals MS25036-XXX As Required XXX = Size
Environmental Splices M81824/1-X As Required X = Size
Solder Sleeves M83519-1-X As Required X = Size
Push/Pull (manually resettable)
Circuit Breaker
MS26574-X 3 Refer to Section 2.4
Technical Specifications for
Circuit Breaker size
requirements. X = Size
Table 3-11 KDC 100EXP Installation Kit PN 89000138-002
