89000109-002 xVue Touch Installation Manual
Rev 2 Page 3-9
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Straight AN816-4D to 1/8 inch, NPT
Male or
Elbow AN822-4D to 1/8 inch, NPT
Male
Commercially
Available
1 Fitting (Static)
Straight AN816-4D to 1/8 inch, NPT
Male or
Elbow AN822-4D to 1/8 inch, NPT
Male
Commercially
Available
1 Fitting (Pitot)
Pitot/Static Hose (match to
individual aircraft’s needs)
Commercially
Available
A/R A combination of different
materials can be used for
the pitot /static lines
Nutplates #8-32 MS21061L08 or
MS21071L08
4 Orientation is optional as
long as minimum edge
distance is maintained
Nutplates #4-40 MS21069L04 or
MS21071L04
4 Orientation is optional as
long as minimum edge
distance is maintained
Rivets MS20426AD3-X 16 X = size
#10-32 Rivet nuts NAS1329A3KXX 4 XX = size
Stainless Steel Mounting Screws #6-
32
MS35206-230 4
Washer head screws AN525-10R 4
Washers AN960-10 4
Tie Wraps or Lacing Cord Commercially
Available
As Required
Non-pressure vessel mounting
sealant, DOW Corning 3145
MIL-A-46146 As Required
Pressure vessel mounting sealant, PS
870B-1/2
MIL-PRF-81733D As Required
Thread-locking compound Commercially
Available
As Required
Bonderite M-CR 1132 Aero -
Conversion coating
1445846 As Required
Thread-seal tape (PTFE) Commercially
Available
As Required
Self-Fusing Silicon Tape, 3M 83010 Commercially
Available
As Required
Table 3-13 Installation Materials Required but Not Supplied
Description PN or Specification Quantity Note
