89000109-002 xVue Touch Installation Manual
Rev 2 Page 5-2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
27 SPARE_BOX_RS422_RX_B In Reserved
28 SPARE_BOX_RS422_RX_A In Reserved
29 SPARE_BOX_RS422_TX_B Out Reserved
30 SPARE_BOX_RS422_TX_A Out Reserved
31 NAV1_ROLL_STR_IN_N In Reserved
32 NAV1_ROLL_STR_IN_P In Reserved
33 LOC_ENERGIZE Out Included
34 HEADING_VALID_DOGO Out Included
35 ADAHRS1_A429_RX_B In Included
36 ADAHRS1_A429_RX_A In Included
37 ADAHRS1_A429_TX_B Out Included
38 ADAHRS1_A429_TX_A Out Included
39 GPS_2_GAMA_429_RX_B In Included
40 SPARE_A429_RX_B In Reserved
41 SPARE_A429_RX_A In Reserved
42 KA_52-57_P15V_PWR PWR Reserved
43 AFCS_DATUM_VAL_DO5VO Out Reserved
44 AFCS_CRS_DATUM_OUT Out Included
45 AFCS_CMD_BAR_RTRCT_DI15VO In Included
46 AFCS_CMD_BAR_ROLL_IN_N In Included
47 AFCS_CMD_BAR_ROLL_IN_P In Included
48 AFCS_CMD_BAR_PITCH_IN_N In Included
49 AFCS_CMD_BAR_PITCH_IN_P In Included
50 NAV1_2_ROLL_STR_OUT_REF GND Reserved
51 GS_FLAG_- GND Included
52 GS_+_DOWN GND Included
53 NAV_FLAG_- GND Included
54 NAV_DEV_+_LT GND Included
55 AFCS_DATUM_OUT_REF GND Included
56 ADAHRS2_A429_RX_B In Reserved
57 ADAHRS2_A429_RX_A In Reserved
58 GPS_1_GAMA_429_RX_B In Included
59 GPS_1_GAMA_429_RX_A In Included
60 EFIS_CTL_429_TX_B Out Included
61 EFIS_CTL_429_TX_A Out Included
62 KA_52-57_N15V_PWR PWR Reserved
J1 Pin Description I/O Initial Certification
