89000109-002 xVue Touch Installation Manual
Rev 2 Page 5-7
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
7 Excitation Square Wave 10VAC In
8AGND GND
9 Chassis Ground GND
10 Analog Pitch Angle Out
11 Analog Roll Angle Out
12 Analog Yaw Rate Out
13 AGND (Analog Yaw Rate Reference) GND
14 Temp Probe 1 In
15 Temp Probe 2 In
16 Temp Probe 3 In
17 Not Used N/A
18 Power GND In
19 Power GND In
20 Power GND (Spare) In
21 RS-232 Ch0 TXD Out
22 RS-232 Ch0 RTS Out
23 RS-232 Ch0 RXD In
24 RS-232 Ch0 CTS In
25 DGND GND
26 RS-232 Ch1 TXD Out
27 RS-232 Ch1 RTS Out
28 RS-232 Ch1 RXD In
29 RS-232 Ch1 CTS In
30 DGND N/A
31 A429 TX2 A Out
32 Yaw Rate Pseudo Valid Pos Out
33 Yaw Rate Pseudo Valid Neg Out
34 A429 RX0 A In
35 A429 RX0 B In
36 Chassis GND GND
37 A429 RX1 A In
38 A429 RX1 B In
39 Chassis GND GND
40 A429 TX0 A Out
41 A429 TX0 B Out
42 Chassis GND GND
J71 Pin Description I/O
