DATABASE LOAD FAIL
NAVIGATION
OBSTACLE
CARTOGRAPHIC
TERRAIN
CHARTS
IFR LOW ALTITUDE
IFR HIGH ALTITUDE
VFR SECTIONAL
Database CRC Failed During
Database Loading
• Reload failed database
• Re-download failed database
source content to USB drive and
reload failed database
• Reload failed database using a
different USB drive
• If fault persists, replace KSD
100EXP
Database Has Failed to Load
• Reload failed database
• Re-download failed database
source content to USB drive and
reload failed database
• Reload failed database using a
different USB drive
• If fault persists, replace KSD
100EXP
Database Tiles Failed to Load
During Run Time
• Reload failed database
• Re-download failed database
source content to USB drive and
reload failed database
• If fault persists, replace KSD
100EXP
Database Tiles Corrupted During
Run Time
• Reload failed database
• Re-download failed database
source content to USB drive and
reload failed database
• If fault persists, replace KSD
100EXP
DATABASE EXPIRED Database(s) has expired Download the latest database(s)
DATABASE FUTURE CYCLE
Newer version of a database has
loaded before the effectivity date
Verify database effectivity date
UAT NO COMMUNICATION
No Data Received on the Bus from
the UAT Receiver
See “UAT FAIL” troubleshooting
procedure in this table.
UAT POSITION FAIL The UAT’s GPS position is invalid
If the UAT’s GPS is used for ADS-B
Out, ADSB Out is no longer
provided
SET BARO BARO is not set Set BARO to current setting
AHRS IN-MOTION ALIGMENT AHRS is in alignment during flight
Fly straight and level If possible
until system is done with
alignment.
Table 8-6 Alerts Troubleshooting Chart
Symptom Causes Corrective Action
