89000109-002 xVue Touch Installation Manual
Rev 2 Page 2-14
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Notes:
1. Duplicate testing not required per DO-160G Section 16.6.1.2’s Note.
2. No test performed since LRU has a metallic enclosure.
3. Analysis only – Metallic enclosure, no vent holes
4. Up/Down= 3.0g, Fwd/Aft/Side=20.0g
5. Conducted Susceptibility (CS) testing was performed using DO-160E Cat A per FAA Policy PS-ACE-23-10.
6. Radiated Susceptibility (RS) testing was performed using the following levels per FAA Policy PS-ACE-23-10:
7. The Outside Air Temperature (OAT) parameter was tested to DO-160G Category R for both (CS) and (RS).
Table 2-12 KG 71EXP Environmental Qualification Form (EQF)
DO-160G
Section
Conditions Category Notes
Frequency
DO-160G
Sect 20 Category
V/m
SW/CW PM
100 - 200 MHz Cat G 100 -
200 - 400 MHz Cat G 100 -
400 - 700 MHz Cat F 25 350
700 MHz – 1 GHz Cat F 50 350
1 - 2 GHz Cat D 50 500
2 - 4 GHz Cat D 50 750
4 - 6 GHz Cat D 50 750
6 - 8 GHz Cat D 50 250
8 - 12 GHz Cat D 75 750
12 - 18 GHz Cat D 50 500
