Programmer 105
Chapter 2 Programming with Help Function
Inputting the trigger (BAS-300 Series)
* This function is not available to KE-436B, 436C.
Input the trigger for the extended option output.
Adjust the needle position before inputting the trigger and setting attribute.
Refer to "Checking the program setting and setting attribute" (page 109).
1. Select and press .
2. Input the option output number.
3. Move with , then use to specify whether to stop the machine or not.
ON: The needle stops at the upper end
without thread breakage, and restarts
after output of the extended option.
OFF: Sewing does not stop.
To Next Page
