Brother BAS-311F-0 - Creating a Circle (Zigzag Circle) by Specifying the Diameter

Programmer 167
Chapter 3 Programming with Command Function
Creating a circle (zigzag circle) by specifying the diameter
Command to be used
Creating a circle clockwise. Input the overlap stitch counts in Values 0 -
9 are available for input.
Creating a circle counterclockwise. Input the overlap stitch counts in .
Values 0 - 9 are available for input.
Input this command to create a zigzag circle. Input the width of zigzag in
.
"Creating a circle (zigzag circle) by specifying 3 points"
(Refer to page 165.)
Input this command to create a zigzag circle. Input the zigzag stitch length
in
.
"Creating a circle (zigzag circle) by specifying 3 points" (Refer to page 165.)
1. Select the sewing start position with and press .
2. Input or .
3. Input the stitch length in 3 digits and press .
