44 Programmer
Chapter 2 Programming with Help Function
Splitting
Different patterns, splitting each pattern in sequence, are
programmed. The example in the left is used for explanation
of 3 patterns in sequence.
Programming
1. Press .
The work clamp moves to the home position and
the programmer screen is displayed.
2. Select with and press .
3. Move the work clamp with
. Press
when the needle point is at point A of the pattern.
The first stitch (point A) is programmed.
4. Program pattern 1.
5. Press
when the needle point is at point B of
the pattern.
The number of pressing depends on the
programming method for pattern 1.
6. Select with and press .
7. Move the work clamp with
. Press
when the needle point is at point C of the pattern.
To Next Page
