88 Programmer
Chapter 2 Programming with Help Function
If are selected
1. Input the stitch length and the overlap stitch count, then press .
Values of 0 - 9 are available for input.
2. Move the needle with and press .
Creating an arc
1. Select and press .
2. Input the stitch length and press .
3. Move the needle with to select the second point, then press .
Press for selection.
Stitch length
Stitch count for overlap sewing
Remaining plot count
Distance from the previous point
in the direction of X or Y axis
Stitch length
Remaining plot count
Distance from the previous point
in the direction of X or Y axis
