34 Programmer
Chapter 2 Programming with Help Function
Double stitch
A double stitch is programmed to make two lines with a
constant width.
The example in the left is used for explanation of a double
stitch to the left of sewing direction.
When the line changes from straight to curve as in points B or E, be sure to press
twice to
make a split.
More intermediate points such as points C or D will create smooth curves.
Programming
1. Press .
The work clamp moves to the home position and
the programmer screen is displayed.
2. Select with and press .
3. Move the work clamp with
. Press
when the needle point is at point A of the pattern.
The first stitch (point A) is programmed.
4. Select with and press .
5. Select the double stitch type and press
.
6. Input the stitch length and the width of the
double stitch. Press
.
3.0 mm is input in the example.
Input 030 to make the stitch length to 3.0 mm.
To switch input between the stitch length and the
width, use
.
