Brother BAS-311F-0 - Adding Escape Point before the First Stitch

Programmer 65
Chapter 2 Programming with Help Function
Adding escape point before the first stitch
An escape point is added before the sewing start position.
The example in the left is used for explanation of setting
escape point A.
The escape point is a provisional point provided for prevention of the work clamp interference
with the needle or the bar leg when the work clamp is lifted at the start point.
Calling data
1. Press .
The work clamp moves to the home position. The
programmer screen is displayed.
2. Select with and press .
3. Select
with and press .
4. Input the data number and press
.
5. Press
.
Moving to position 1
1. Select with and press .
2. Press
and press .
The work clamp moves to the sewing start
position.
3. Press .
