132 Programmer
Chapter 3 Programming with Command Function
Ending program
1. Press .
Double stitch
A double stitch is programmed to make two lines with a
constant width.
The example in the left is used for explanation of a double
stitch to the left of sewing direction.
When the line changes from straight to curve or curve to straight as in points B or E, be sure to
press
to make a split.
More intermediate points such as points C or D will create smooth curves.
Programming
1. Press .
The work clamp moves to the home position and
the programmer screen is displayed.
2. Move the work clamp with . Press
when the needle point is at point A of the
pattern.
The first stitch (point A) is programmed.
3. Press and press .
is the command for the double stitch.
Input the width of the double stitch in
. 3.0
mm is input in the example.
4. Input the stitch length and press .
3.0 mm is input in the example.
Input 030 to make the stitch length to 3.0 mm.
5. Create the program to point F in the similar
manner of curve program.
If a straight line is present as in the example, press
at the end of the line.
To Next Page
