Programmer 25
Chapter 2 Programming with Help Function
Programming example
Frequently used programming method is explained here. Refer to "Programming" (page 85) for
function and operation of each icon.
Programming for each stitch
Program each stitch according to the pattern. The example in
the left is used for explanation.
Programming
1. Press .
The work clamp moves to the home position and
the programmer screen is displayed.
2. Select with and press .
3. Move the work clamp with
. Press
when the needle point is at point A of the
pattern.
The first stitch (point A) is programmed.
4. Select with and press .
5. Move the work clamp with
. Press
when the needle point is at point B of the
pattern.
6. Repeat step 5 and create the program to point
C.
To Next Page
