46 Programmer
Chapter 2 Programming with Help Function
2. Select with and press .
3. Input the data number and press
.
4. Press
.
Ending program
1. Press .
Zigzag stitch
Zigzag stitch is programmed. The example in the left is used
for explanation of even width of zigzag stitch on the sewing
path.
Zigzag with curves may be programmed.
Programming
1. Press .
The work clamp moves to the home position and
the programmer screen is displayed.
2. Select with and press .
3. Move the work clamp with
. Press
when the needle point is at point A of the
pattern.
The first stitch (point A) is programmed.
To Next Page
