Programmer 47
Chapter 2 Programming with Help Function
4. Select with and press .
5. Select
with and press .
6. Input the zigzag width and the stitch length and
press
.
3.0 mm is input in the example.
Input 030 to make the width and the stitch length
to 3.0 mm.
To switch input between the stitch length and the
width, use
.
7. Move the work clamp with . Press
when the needle point is at point B of the
pattern.
To program curves, repeat this step.
8. Press again.
9. Press
three times.
Inputting the end code
1. Select with and press .
2. Select the end code type with
and press
.
"111" is selected in the example. Press and the
work clamp returns to the first stitch (point A).
3. Press .
The work clamp returns to the home position.
