144 Programmer
Chapter 3 Programming with Command Function
Example of modified program
This section describes the modification method of the program using examples. Refer to
"Programming" (page 163).
Resizing pattern
The programmed pattern is resized. The example in the left is
used for explanation.
The center point (reference point) of resizing can be changed. The magnifying direction varies
depending on the position of the reference point.
If the reference point is not determined, the pattern is resized to the home position.
If the reference point is determined, the pattern is resized to the reference point.
Calling data
1. Specify the program number on the operation
panel and press the read/write switch to read
the data.
To Next Page
