Programmer 203
Chapter 4 Extended Option Output
Table of condition number
Select and input the number for output conditions, enabling conditions and disabling conditions from
the following:
Machine operation mode
Condition
No.
Operation meeting the condition
1 After a feed is complete at the home position
2 After a feed is complete at the sewing start position (at escape point, if applicable)
3 Before sewing or a test feed is started from the sewing start position
(or the start position)
4 Before the machine upper shaft starts rotating at the first stitch
5 Before a test feed is started at the first stitch
6 After sewing or a test is complete
(before moving to sewing start position or escape point)
7 After an emergency stop is reset
8 After a step back is started
9 Before halfway sewing is started
10 After the lower thread counter changes from 1 to 0 and the lower thread needs to be
replaced
11 After the lower thread is replaced
12 After a program is started
13 After a program is complete
14 When a trigger data is detected during sewing
15 After an emergency stop occurs
16 After a thread breakage occurs
17 After a program is changed
18 After the power switch is turned on
19 After a low air pressure error is detected
20 Before movement to the next start position on completion of sewing in the split mode
21 After completion of sewing in the split mode and movement to the next start position
Standard input
Condition
No.
Operation meeting the condition
25 When the foot pedal is effective (before the work clamp moves up or down)
26 When the start pedal is effective (before starting operation)
