180 Programmer
Chapter 3 Programming with Command Function
3. Create a pattern data.
Move the needle with , then press for setting.
4. Input the end code.
Low-speed sewing
Carry out setting for low-speed sewing.
Command to be used
The maximum sewing speed becomes 400 rpm or lower.
The maximum sewing speed becomes 1200 rpm or lower.
The maximum sewing speed becomes 800 rpm or lower.
The maximum sewing speed becomes 600 rpm or lower.
Canceling setting for low speed data
1. Move to the desired needle position for setting.
Refer to “Moving needle point” (page 123).
2. Select the type of low speed sewing and input the command.
If multiple settings are required, input the stitch counts in 3 digits continuously and press .
