Programmer 121
Chapter 3 Programming with Command Function
Display screen
Press and the following screen appears.
If the screen is not displayed, press
.
Programming flowchart
Programming
Position the sewing start position and press .
Input the command for programming.
(Refer to page 163.)
Combine straight lines, curves and other figures to make patterns to the pattern sheet. After completing
each pattern, press .
The data is available until deletion.
Input end code.
(Refer to page 181.)
Displays the command status. Displays distance from the home position.
Displays distance from the
previous needle position.
Displays the end code,
if applicable.
Displays the stitch length.
Displays the input value.
Displays the current needle
position/total stitch count.
To Next Page
