Programmer 149
Chapter 3 Programming with Command Function
Changing the first stitch position
The position of the sewing start position is changed. The
example in the left is used for explanation of moving the
sewing start position from 1 to 1'.
Calling data
1. Specify the program number on the operation
panel and press the read/write switch to read
the data.
Moving to position 1.
1. Press and press .
The work clamp moves to the start position.
Programming a new point.
1. Move the work clamp with . Press
when the needle point is at 1' of the pattern.
1' is programmed.
Deleting 1
1. Press and press .
The needle point returns to the first stitch.
2. Press .
3. Input the number of stitches to be deleted and
press
.
The example is deleting 1 stitch. Press .
To Next Page
